Different optic will be used for different combo to achieve best performance.
For example, for W1/SFT-25R LED + 519A/SST-20 combo, N244SW optic will be used.
E21A+E21A, 10623 optic will be used, etc.
If you have preferable of which type of optic to be installed in your light, please shoot us an email.
The light works with flat top, unprotected battery only, button top or protected battery may damage the light
Anduril 2 firmware, user choose the tint ramping or instant channel switching (operation video for reference)
Advanced mode Off -> 9H, first menu item:
0C: tint-ramping (smooth)
1C: instant channel switching
Warning: Output will be dependent on cell model (incl.age) and temperature.
Emisar D4V2 Cu puts a high lumen output but generates a lot of heat at the same time, please acknowledge before purchasing.
High drain, flat top, unprotected battery required. (not included in the price)
D4V2 reflashing kit purchase link
Review:https://youtu.be/H5EgBO5xWBY
Features:
• CNC machined from Copper.
• Efficient UK made Carclo Quad LED optics.
• Anti-reflective coated glass lens
• Unihead construction
• High lumen output and low moon output
• Ramping interface
• Electronic soft touch switch
• Beryllium-Copper springs with 45% IACS superior to stainless steel alloys used for springs with only 2% IACS.
• Temperature step-down
• Waterproof and dustproof to IP67 standard (up to 1 meter)
• Default 18650 body with optional 18350 battery tube
• Dimensions: 96mm(length) * 28mm(head) * 24mm(body), 65mm(lenght 18350)
OTF lumen output at start-up:
SST-20 6500K: 4200lm
SST-20 5000K: 4200lm
SST-20 4000K/3000K 95CRI: 3000lm
Nichia E21A version: 1200lm
This product uses free software distributed under the terms of the GPLv3.
Source code is available from https://toykeeper.net/anduril
